Windows Vista, Windows Server 2008:
1. On the [Start] menu, click [Control Panel].
The [Control Panel] window appears.
2. Click [Printer].
The [Printers] window appears.
3. Right-click the icon of the printer you want to use, and then click [Properties].
4. Click the [Ports] tab, and then click [Configure Port].
The [Port Configuration:] dialog box appears.
• User, proxy, and timeout settings can be configured for IPP.
• If no settings on the [Recovery/Parallel Printing] tab are available, follow the procedure below.
1. Click [Cancel] to close the [Port Configuration:] dialog box.
2. Start SmartDeviceMonitor for Client, and then right-click the SmartDeviceMonitor for Client icon
on the tasktray.
3. Point to [Properties], and then click Extended Features Settings.
4. Select the Set [Recovery/Parallel Printing] for each port check box.
5. Click [OK] to close the [Extended Features] dialog box.
• For details about these settings, see "Using SmartDeviceMonitor for Client", or SmartDeviceMonitor
for Client Help.
• p.208 "Using SmartDeviceMonitor for Client"
Installing the PCL / RPCS printer drivers (TCP/IP)
• To install this printer driver under Windows 2000/XP/Vista, and Windows Server 2003/2003
R2/2008, you must have an account that has Manage Printers permission. Log on as an
Administrators or Power Users group member.
1. Quit all applications currently running.
2. Insert the CD-ROM into the CD-ROM drive.
The installer starts.
3. Select an interface language, and then click [OK].
The default interface language is English.
4. Click [PCL/RPCS Printer Drivers].
Installing the Printer Driver
23
