Ricoh CL4000DN Quick Installation Guide

7. Holding the SDRAM module at an angle, press it down until it clicks into place.
BMU115S
8. Match the controller board to the top and bottom rail using the " " mark, and then slide it
into the printer slowly until it stops.
BMU025S
9. Push the handle of the controller board until it clicks.
BMU026S
2. Installing Options
38
2
