10. Fasten the controller board to the printer with the two screws.
BMU027S
Use a coin or similar object if the screws do not turn easily.
After finishing the installation, you can check the memory unit is properly installed: Print the
configuration page from the [List/Test Print] menu. If it is installed properly, the memory capacity will
appear under "Total Memory" on the configuration page.
The table below shows the total SDRAM module capacities.
Standard Extended Total
256 MB 128 MB 384 MB
256 MB 256 MB 512 MB
If the memory unit is not properly installed, repeat this procedure. If you cannot install it properly even
after reinstallation, contact your sales or service representative.
Install the controller board carefully to prevent any malfunction.
"Printing the Test Page", Quick Installation Guide.
Installing the Memory Expansion Units
39
