3. Connect the other end of the cable to the network, such as a hub.
Connecting to the Ethernet port of the Gigabit Ethernet board
1. Attach the ferrite core at the Gigabit Ethernet cable.
Attach one ferrite core at the printer end of the Ethernet cable, and attach the other ferrite core about
10 cm (4 inches) ( ) from this core making a loop as shown.
3. Connecting the Printer Cables
54
