BMU300S
Attach the other ferrite core about 10 cm (4 inches) ( ) from this core making a loop as shown.
BMU301S
2. Connect the Ethernet cable to the Gigabit Ethernet board.
BMU096S
Ethernet Cable Connection
55
3
