Ricoh MET-C1 - Scanner Unit

Scanner Unit
• When you replace the scanner wire, use the standard positioning pins.
Scanner Exterior
Scanner Upper Cover
1. Platen cover or ADF
2. Scanner rear cover (page 232)
3. Scanner Upper Cover [A] ( ×2)
Scanner Right Cover
1. Scanner rear cover (page 232)
