[C] Controller Box Cooling Fan
[D] Controller Board
[E] HDD
Printed Circuits Behind the Controller Box.
[A] HVP_TTS
[B] Imaging IOB
Printed Circuit/Parts Inside the Power Box
4. Replacement and Adjustment
392
