Ricoh MET-C1 - Scanner HP Sensor

4. SIO [A] ( ×4, ×7)
Scanner HP Sensor
1. Scanner upper cover (page 250)
2. Exposure glass (page 252)
3. Slide the exposure lamp (1st scanner carriage) [A] in the direction of the arrow a little.
4. Replacement and Adjustment
260
