Ricoh MET-C1 - Bin Tray BN3110; Accessory Check; Installation Procedure

1 Bin Tray BN3110
Accessory Check
No. Description Q’ty
1 TRAY:SUPPORT:ASS'Y 1
2 TRAY:EXIT:ASS'Y 1
3 GEAR:Z22 1
4 COVER:TRAY 1
5 TAPPING SCREW:ROUND POINT:3X8 2
Installation Procedure
• When installing this option, turn the machine power off, and unplug the power plug from the wall
socket. If it is installed with the power on, it will result in an electric shock or a malfunction.
• If you install this option together with “Side Tray Type M3”, first install this option, and then install
“Side Tray Type M3”.
1 Bin Tray BN3110
91
