Drive Layout
No.
Description
No.
Description
1
Paper feed motor
12
Toner bottle drive motor (C)
2
Duplex / By-pass motor
13
Toner bottle drive motor (M)
3
Transport motor
14
Toner bottle drive motor (Y)
4
Registration motor
15
Toner transport motor (Y)
5
Paper transfer contact motor
16
Toner transport motor (M)
6
Fusing motor
17
Toner transport motor (C)
