4. Toner supply cooling fan [A]
PSU Cooling Fan
1. Rear lower cover (page 231)
2. PSU cooling fan unit [A] ( ×2, x1, x1)
3. PSU cooling fan [A]
4. Replacement and Adjustment
416
