8. Imaging drive unit [A] ( ×9, ×1)
PCU Motor: CMY
1. Controller box (page 317)
2. Color PCU motor [A] ( ×4, ×1)
Development Motor: CMY
1. Bracket (page 318)
2. Color Development motor [A] ( ×4)
Development solenoid
1. Controller box (page 317)
2. Power supply box (page 405)
4. Replacement and Adjustment
320
