6. Environment
Environment
Energy Saver Modes
Customers should use energy saver modes properly, to save energy and protect the environment.
The area shaded grey in this diagram represents the amount of energy that is saved when the timers are
at the default settings. If the timers are changed, then the energy saved will be different. For example, if
the timers are all set to 240 min., the grey area will disappear, and no energy is saved before 240 min.
expires.
*1. The settings related to Low Power Mode are available only when setting “1” on SP5101-104.
SPs for setting energy saver mode
SP name Value NA EU CHN TWN Asia
SP5101-004
(Timer Set: Low
Power)
Min. 60(s) 60(s) 60(s) 60(s) 60(s)
Default 60(s) 60(s) 60(s) 60(s) 60(s)
Max. 1800(s) 1800(s) 14400(s) 14400(s) 14400(s)
Step 1(m) 1(m) 1(m) 1(m) 1(m)
641
