Ricoh MET-C1 - Pcu;Development Unit; Before Replacing a PCU

4. Release the lock for the ITB contact/separation lever [A].
5. Remove the PCDU.
[A] Y x 1, x 1
[B] M x 1, x 1
[C] C x 1, x 1
[D] K x 1, x 1
PCU/Development Unit
Before replacing a PCU
• Before replacing a PCU, do the procedure shown below. The main points are as follows.
• Input the charge voltage correction value for the new PCU.
PCDU
283
