IEEE 1284 Interface Board Type A
Accessory Check
No. Description Q’ty
- PCB:IEEE1284:ASS'Y 1
Installation procedure
• When you install this option, Switch the MFP’s power supply OFF, and unplug the power plug from
the mains outlet.
• Do not put your hand into the controller box. It will result in a malfunction or injury.
• Before doing any work, touch a metal object to discharge static electricity from the body. There is a
possibility that the IEEE 1284 Interface Board may malfunction due to static electricity.
1. I/F slot B [B] ( ×2) covers.
2. Attach the IEEE 1284 Interface Board to the I/F slot ( ×2)
2. Installation
174
