Service Call 324-396
SC300 (Engine: Charge, Development)
SC No. Level Error Name/Error Condition/Major Cause/Solution
SC324-01 D Development motor: Bk: Lock
Lock signals are observed at 2 sec intervals during motor ON, and a
High level is detected at least 20 times
• Motor defective
• Connector disconnected
• Harness broken
• IOB defective
• Development unit torque increased
• Replace the motor
• Reconnect the connector
• Replace the harness
• Replace the IOB
• Replace the development unit
• Replace the drive unit
