Ricoh Printer/Scanner Unit Type 8000 Network Guide

Monitoring and Configuring the Printer
68
2
• wlan can be specified only
when the IEEE 802.11b interface
is installed.
❖ Initializing the printer name for each
interface
msh>hostname “interface
_name” clear name
ifconfig
Use the "ifconfig" command to view
and configure TCP/IP (IP address,
subnet mask, broadcast address, de-
fault gateway address) for the printer.
❖ View settings
msh> ifconfig
❖ IPv4 Configuration
msh> ifconfig “interface
_name” “parameter” “ad-
dress”
• If you did not enter an interface
name, it is automatically set to
the Ethernet interface.
• ip1394 can be specified only
when the IEEE 1394 interface is
installed.
• wlan can be specified only
when the IEEE 802.11b interface
is installed.
The following explains how to
configure an IPv4 address
192.168.15.16 on Ethernet inter-
face.
msh> ifconfig ether 192.168.
15.16
❖ IPv6 Configuration
msh> ifconfig ether inet6
interface_name ” “printer
_name”
The following explains how to
configure a IPv6 address to
2001:DB8::100 with prefix length
64 on the Ethernet interface.
msh> ifconfig ether inet6
2001:DB8::100 64
❖ Netmask configuration
msh> ifconfig “interface
_name” netmask “address”
The following explains how to con-
figure a subnet mask 255.255.255.0
on Ethernet interface.
msh> ifconfig ether net-
mask 255.255.255.0
❖ Broadcast address configuration
msh> ifconfig “interface
_name” broadcast “address”
Interface name Interface config-
ured
ether Ethernet interface
ip1394 IEEE 1394 interface
wlan IEEE 802.11b inter-
face
Interface name Interface config-
ured
ether Ethernet Interface
ip1394 IEEE 1394 Inter-
face
wlan IEEE 802.11b Inter-
face
