2.Detailed Descriptions
131
The three feed belts are installed at the same level. This improves the suction power and the feed
quality for long paper.
Fan Shutter Mechanism
There is no shutters for the side fan, so air from the side fan (side air) always blows through while paper
is transported.
1. Just before feed (first sheet of paper only)
The float/separation fan, side fan, suction fan shutters open, but the return fan shutter does not.
The feed belt [A] stops.
