6.5 INITIALIZATION OF BOOTSTRAP
RIELE BERLIN Photometer 5010 / V4 6.14 25.08.2003
25. Date and time can be set (see OM chapter 8.2.13 - Real time clock ON / OFF):
Confirm with [ENTER].
26. Photometer 5010 performs a reset operation. The display shows an error:
Confirm the error with [ENTER].
27. The display of Photometer 5010 shows:
28. The serial number can be set by applying the service tool S4.
See Service Manual chapter 3.4 - S4 Serial number.
29. The assignment of filter positions has to be done if there are additional filters build in
(e.g. 623 nm). Apply the tool S6.
See Service Manual chapter 3.4 - S6 Filter select.
30. Make a setting of temperature values by applying the service tool S8.2 / S8.3.
The values are noted on the instrument card.
Besides the values are noted on a sticker.
See Service Manual chapter 4.40 - Thermal adjustment.
See Service Manual chapter 3.4 - S8.2 Temperature value of standard cuvette adaptor.
See Service Manual chapter 3.4 - S8.3 Temperature value of flowthrough cuvette adaptor.
31. Make a setting of “attribut of PCB layout“ by applying the service tool S13:
Software applications may be dependent on this attribut.
See Service Manual chapter 3.4 - S13 Attribut of PCB layout.
32. Make a dark level adjustment by applying utility U1 in combination with flow-through system.
See OM chapter 8.2.1 - Dark level adjustment.
The utility is working specific to the current adaptor. An adjustment of the standard cuvette
adaptor should be done later on.
33. Make a media test by applying utility U2.
See OM chapter 8.2.2 - Adjustment of bubble detector.
34. Perform a pump calibration by applying MODE FUNCTION - Pump utilities - Calibration.
See OM chapter 5.7 - Pump calibration.
35. Switch off Photometer 5010. Change the cuvette adaptor. Switch on Photometer 5010
36. Make a dark level adjustment by applying utility U1 in combination with standard cuvette
adapter.
See OM chapter 8.2.1 - Dark level adjustment.
37. Control the settings by applying utility U12.
See OM chapter 8.2.12 - Printing device configuration.
PHOTOMETER 5010
ERROR 8
METHOD NO.
INPUT 1-250
DATE mm.dd.yy
TIME hh:mm:ss
