3.3 SERVICE TOOLS
RIELE BERLIN Photometer 5010 / V4 3.3.8 19.09.2003
S12 Reduction of lamp voltage
The voltage + 12 V
DC
of halogen lamp can be reduced for lamp adjustment in vertical direction.
Start menu by [MODE] [LF] [12]:
Confirm with [ENTER].
Confirm with [ENTER]. Adjust lamp in vertical direction.
Press [BREAK] for exit.
S13 Attribut of PCB layout
The attribut of the PCB layout can be read and set. Software applications may be dependent on this attribut.
The attribut is labeled on the PCB RR_111 near plug ST13 (RS232C interface).
Start menu by [MODE] [LF] [13]:
Confirm with [ENTER].
Confirm with [ENTER].
In the second line the display shows the version of PCB layout, e.g. the value „c“.
Change the value by [+] in case of a deviation and confirm the input by [ENTER].
Leave the window by [BREAK] in case of no change.
S14 Patients data initialization
The memory of patients data mangement is cleared completely.
Start menu by [MODE] [LF] [14]:
The memory is cleared by confirming with [ENTER].
This action ends with a long beep.
PCB LAYOUT S13
SERVICE TOOLS
DEL.PATIENTS S14
SERVICE TOOLS
LAMP DOWN S12
SERVICE TOOLS
PCB LAYOUT S13
c +EB
