3.3 SERVICE TOOLS
RIELE BERLIN Photometer 5010 / V4 3.3.7 19.09.2003
S9 Block Code Character from method
To check the correct storing of a user-defined method, the special test byte BCC concerning the data in the
memory is used. With this service program the BCC of a method can be determined.
Start menu by [MODE] [LF] [9]:
Confirm with [ENTER].
The number of the concerning method must be entered and confirmed with
[ENTER]. Then the BCC is displayed in the decimal form.
Press [ENTER] and select another number of a method.
Press [BREAK] for exit.
S10 Analog-digital converter correction
Display of the actual correction value of the analog-digital converter (photometric measuring system). In the
delivering condition the value is 75.
Start menu by [MODE] [LF] [10]:
Confirm with [ENTER].
By input of a correction value between 0 and 255 and confirming with [ENTER]
measurements seeming too low can be increased a little bit. This correction
recognizably affects only at high results (~ 2 Absorbance).
S11 Voltages
Display of the actual voltages on the pcb.
Start menu by [MODE] [LF] [11]:
Confirm with [ENTER].
Confirm with [ENTER].
The display shows the actual voltages of
+ 12 V
DC
of halogen lamp / fan (1. line left)
+ 12 V
DC
and - 12 V
DC
of analogic circuits (1. line right)
+ 5 V
DC
of VCC (2. line left)
+ 15 V
DC
of power supply (2. line middle)
V
DC
voltage of Peltier element (2. line right)
BCC FROM METH.S9
SERVICE TOOLS
ADC CORRECT.S10
SERVICE TOOLS
VOLTAGES S11
SERVICE TOOLS
12.03 12+0.07
-4.93 14.75 0.01
