Riele Photometer 5010 - S8.4 Temperature Calibration; S8.5 Temperature Required; Actual; S8.6 Temperature Analog-Digital-Converter

3.3 SERVICE TOOLS
RIELE BERLIN Photometer 5010 / V4 3.3.6 19.09.2003
S8.4 Temperature calibration
The correction of the temperature regulation is possible by input of the temperature which is measured in the
cuvette with an external measuring system (only when the temperature regulation is stabilized).
Start menu by [4]:
Confirm with [ENTER].
Confirm with [ENTER].
The display shows the current temperature level at the required value of 37 °C.
Enter the actual temperature value always four-digit in °C e.g. [3] [7] [,] [2] [0]
[ENTER] measured by an external measuring system. The system calculates and
stores the new setting for 37.0 °C and starts working with it at once.
S8.5 Temperature required / actual
The correction of the temperature regulation is possible by input of the temperature which is measured in the
cuvette with an external measuring system (only when the temperature regulation is stabilized).
Start menu by [5]:
Confirm with [ENTER].
Confirm with [ENTER].
The display shows in the second line the required value (e.g. 14270),
the actual value (e.g. 14275) and the type of cuvette adapter (e.g. D).
S8.6 Temperature Analog-Digital-Converter
Display of the counter value of the temperature ADC and of the current stability value.
Start menu by [6]:
Confirm with [ENTER].
Confirm with [ENTER].
The display shows in the second line the actual value of the ADC (e.g. 954),
and the stability value S (e.g. 0).
TEMP. CALIBR.
INPUT +/E/B
INPUT DEGREE C
37C 37.20
TEMP. REQU / ACT
INPUT +/E/B
TEMP. REQU / ACT
14270 14275 D
TEMP. ADC
INPUT +/E/B
TEMP. ADC
ADC 954 S 0
