4.11 FILTER WHEEL ID 5010-004
RIELE BERLIN Photometer 5010 / V4 4.11.3 04.09.2003
4. Press [MODE], [LF] for entering service level
PASSWORD
SERVICE TOOLS
5. Enter password [13467] for entrance into service level
PASSWORD 13467
SERVICE TOOLS
6. Press [ ↵ ]
7. The instrument is ready for operations in service level and the display shows:
INPUT 1-n/+
SERVICE TOOLS
8. Press [7], [ ↵ ] for editing wavelength
FILTERSELECT S7
SERVICE TOOLS
9. Press [ ↵ ]
10. Select corresponding hole ( e.g. 7 ) of the filter wheel with [ + ] and [ ↵ ]
FILTER
F7 999NM +-#
9. Enter the value of the new wavelength ( e.g. 670 )
FILTER
F7 999NM 670#
11. Press [ ↵ ]
12. The display shows:
FILTER
F7 670NM +-#
13. Press [BREAK], [BREAK]
14. Press [MODE], [MODE], [ 9 ], [ ↵ ], [ ↵ ], [ ↵ ] for control of ADC-counter value in corresponding filter
position (OM chapter 8.2.9 / AD-Transducer measurands).
Select corresponding hole ( e.g. 7 ) of the filter wheel with [MODE], [ 7 ].
The ADC-counter value should be within a range of 3.000 and 600.000.
ADC COUNTS 9
0 327180 F7
15. Finish the operation with [BREAK]
