MPX 130 PWC USER INTERFACE
①
Connectivity Panel (CP)
④
Communication Slots for housing the expansion
cards
②
Power Supply Unit 1 (PSU 1)
⑤
Cold Start [optional]
③
Power Supply Unit 2 (PSU 2) [optional]
The Connectivity Panel is provided with a network
connection to enable the remote operation of the
system.
The right side of the display is equipped with connection
ports (SA ports) that are reserved for trained service
personnel only. Do not connect to the SA ports without
specific instructions.
NOTE: For further information refer to the chapter “Remote Communication and accessories”
