SLIDING SWITCH STATUS
OFF UNAVAILABLE
ON TEMPORARILY UNAVAILABLE
PARTIALLY ON
(SOME ARE “OFF” – SOME ARE “ON”)
TEMPORARILY UNAVAILABLE
OFF - LOCK STATUS TEMPORARILY UNAVAILABLE
ON - LOCK STATUS TEMPORARILY UNAVAILABLE
S YSTEM STATUS DISPLAY
L EGEND OF THE USED SYMBOLS
TOUCH
If present, it highlights the main elements which
can be selected from the screen.
SWIPE
LEFT-RIGHT
Movement for the sliding graphical elements for
the status switch from O to I.
SWIPE
RIGHT-LEFT
Movement for the sliding graphical elements for
the status switch from I to O.
