TECHNICAL DATA TABLE
MPX - from 15/25 to 125 kW
1
INPUT
Voltage [V]
380-400-415V AC 3 phase plus neutral
Voltage tolerance [V]
from 240 to 480
2
Frequency tolerance [Hz]
40-72
Power factor
1
THDI [%]
MPX 15 PM ≤ 4
MPX 25 PM ≤ 3
BYPASS
Nominal power [kW]
60/75/100/126 (depending on the type of Cabinet)
Nominal voltage [V]
380-400-415V AC 3 phase plus neutral
Voltage tolerance [V]
from 180 (adjustable 180-200) to 264 (adjustable 250-264) referring to neutral
Nominal frequency [Hz]
50 or 60
Overload
125% for 10 minutes; 150% for 1 minute
BATTERIES
Modular Type (MPW 170 BTC) Traditional Type
Configuration
Battery units (BU
4
)
9 per battery shelf (36 x BU
4
)
Battery shelf with standalone installation
1 x (20 + 20) batteries
Battery characteristics
VRLA aligned batteries; continuous
measurement of voltage and current;
battery status monitoring via the MPX
LCD display
Traditional VRLA type batteries
Dimensions (WxDxH) (mm)
600x1050x2000 860x800x2000
Weight [kg] (without PM
3
/BU
4
)
280 250
OUTPUT
Nominal voltage [V]
380
2
/400/415V AC 3-phase plus neutral
Nominal frequency [Hz]
50 or 60
Voltage stability [%]
± 1
Dynamic stability
EN62040-3 Performance Class 1 with non-linear load
GENERAL SPECIFICATIONS
Cabinet type
MPX 130 PWC MPX 100 CBC MPX 130 PWC MPX 100 CBC
Power Module nominal power
[kW]
15 (MPX 15 PM) 15 (MPX 15 PM) 25 (MPX 25 PM) 25 (MPX 25 PM)
Nominal power [kW]
75 60 125 100
Output power factor
1 1 1 1
Can be installed in parallel (up
to)
4 4 4 4
Cabinet configuration
5 x MPX 15 PM
4 x MPX 15 PM
6 x batt. shelf
(24 x BU
4
)
5 x MPX 25 PM
4 x MPX 25 PM
6 x batt. shelf
(24 x BU
4
)
Dimensions (WxDxH) (mm)
600x1050x1200 600x1050x2000 600x1050x1200 600x1050x2000
Weight [kg] (without PM
3
/BU
4
)
145 350 145 350
Level of system noise at 1 m
[dBA ± 2]
≤ 65 ≤ 64 ≤ 65 ≤ 64
Cabinet IP Class
IP20
Operating temperature [°C]
0/40
