Riello UPS MULTI POWER MPX - Monitoring Unit Status and Alarm Codes

‐85‐
MONITORING UNIT
MU STATUS MESSAGES
MU NOT PRESENT
Minor
FAULT
Major
ANOMALY
WARNING
NORMAL OPERATION
MU ALARM CODES
COMMAND
[C05]
MANUAL BYPASS ACTIVE
[C06]
EPO COMMAND ACTIVE
ANOMALY
[A61]
BATTERY UNIT ANOMALY
[A62]
BATTERY NOT PRESENT
Major
[A63]
SWBATT OPEN
Major
[A64]
SWEXTBATT OPEN
Major
[A65]
SWIN OPEN
Major
[A66]
SWBYP OPEN
Major
[A67]
SWOUT OPEN
Major
[A68]
BATTERY OVERTEMP
Major
[A69]
CABINET OVERTEMP
Major
FAULT
[F61]
TEMP. SENSOR FAULT S1
[F62]
TEMP. SENSOR FAULT S2
[F63]
TEMP. SENSOR FAULT S3
[F64]
TEMP. SENSOR FAULT S4
[F65]
HUMIDITY SENSOR FAULT
[F66]
HARDWARE FAULT
[F67]
POWER SUPPLY PSU1 FAIL
Minor
[F68]
POWER SUPPLY PSU2 FAIL
Minor
[b+n] *
INTERNAL CODE
[b-n] *
INTERNAL CODE
BU ALARM CODES
WARNING
[W62]
DISCHARGE CURRENT
[W63]
BATTERY CONFIG. ERR.
ANOMALY
[A62]
BATTERY NOT PRESENT
Major
[A71]
CHARGE OVERCURRENT
FAULT
[F69]
ABNORMAL CURRENT
[F70]
ABNORMAL VOLTAGE
[F71]
DISCHARGE CURRENT
[b+n] *
INTERNAL CODE
[b-n] *
INTERNAL CODE
* “n” denotes the shelf identification number with the anomaly (1 - 9)
