Riello UPS MULTI POWER MPX - Status Messages; Alarm Codes; MPX System Status Messages

‐79‐
STATUS MESSAGES / ALARM CODES
MPX SYSTEM
MPX STATUS MESSAGES
Comm Lost
Minor
PMs LOCKED
Critical
BYPASS BACKFEED
Critical
BMs LOCK - OUTPUT OVERLOAD
BMs LOCK - BOARDS LINK FAIL
BMs LOCKED
PARALLEL LINK OPEN
Major
OVERLOAD
Major
BYPASS NOT AVAILABLE
Major
BMs FAULT
Major
LOST REDUNDANCY
Major
POWER SUPPLY PSU1 FAIL
Minor
POWER SUPPLY PSU2 FAIL
Minor
SYSTEM FAILURE
Major
MANUAL BYPASS ACTIVE
Major
SWOUT OPEN
Major
LOW REDUNDANCY
Minor
SWBATT OPEN
Major
SWEXTBATT OPEN
Major
BATTERY NOT PRESENT
Major
BATTERY UNIT ANOMALY
REPLACE BATTERY
Major
SYSTEM ANOMALY
Minor
LOAD THRESHOLD EXCEEDED
BATTERY LOW
Major
IMMINENT SHUTDOWN
Major
SCHEDULED SHUTDOWN
Minor
TEST IN PROGRESS
EPO COMMAND ACTIVE
Critical
SWIN OPEN
Major
SWBYP OPEN
Major
PM NOT COMPATIBLE
Warning
SYSTEM WARNING
Warning
MAINS INPUT FAIL
Major
SWMB MISALIGNED
Major
PM NOT COMPATIBLE
Warning
INPUT CONTACT DISABLED
Warning
DIFFERENT MCU FIRMW. VERSION
Warning
ERRONEOUS SWMB STATUS
Warning
