ICONS AND SYMBOLS
System input mains status % Battery charge gauge
Output % Load gauge phase 1
Automatic static bypass % Load gauge phase 2
Battery % Load gauge phase 3
System status
Redundancy bar (see paragraph “Load
level and redundancy system status”)
In general, the colour and the shape of the icons provide instant information to the status of the system.
Grey colour: communication lost (Com-Lost).
Light blue colour: normal status.
Blue colour: bypass operation.
Orange colour: anomaly.
Red colour: alarm.
