RIGOL Chapter 2 Command System
2-22 MSO1000Z/DS1000Z Programming Guide
:CURSor:MANual:BXValue?
Syntax
:CURSor:MANual:BXValue?
Description
Query the X value of cursor B in the manual cursor measurement mode. The unit depends
on the horizontal unit currently selected.
Return
Format
The query returns the X value of cursor B in scientific notation.
Example
:CURSor:MANual:BXValue? /*The query returns 4.000000e-06*/
Related
Commands
:CURSor:MANual:BX
:CURSor:MANual:TUNit
:CURSor:MANual:BYValue?
Syntax
:CURSor:MANual:BYValue?
Description
Query the Y value of cursor B in the manual cursor measurement mode. The unit depends
on the vertical unit currently selected.
Return
Format
 When the signal source is CHANnel1|CHANnel2|CHANnel3|CHANnel4|MATH, the
query returns the Y value of cursor B in scientific notation.
 When the signal source is LA, the query returns the decimal value corresponding to
the sum of the binary weights of D15 bit to D0 bit at cursor B (the value of the
channel that is not turned on is 0 by default) .
Example
:CURSor:MANual:BYValue? /*The query returns -2.000000e+00*/
Related
Commands
:CURSor:MANual:BY
:CURSor:MANual:VUNit
:CURSor:MANual:XDELta?
Syntax
:CURSor:MANual:XDELta?
Description
Query the difference between the X values of cursor A and cursor B (BX-AX) in the manual
cursor measurement mode. The unit depends on the horizontal unit currently selected.
Return
Format
The query returns the difference in scientific notation.
Example
:CURSor:MANual:XDELta? /*The query returns 8.000000e-06*/
Related
Commands
:CURSor:MANual:AX
:CURSor:MANual:BX
:CURSor:MANual:TUNit

Rigol DS1074Z Plus Specifications

General

Type	Tabletop
Product type	-
Certification	UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001
Bandwidth	70 MHz
Sampling rate	- MS/s
Channels quantity	4 channels
Minimum time base setting (per division)	5 ns
Power consumption (max)	50 W
Display diagonal	7 \
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
