SPIROR HP - DR
4.5.1.UNPACK
1. Take off the cover.
2. Remove the fasteners from all components (plastic strip or wooden dolly blocks).
3. Check to see that all the material is there, and that it is not damaged in any way.
|
Important
Y
ou are advised to kee
p
the
p
acka
g
in
g
material.
4.5.2.ASSEMBLY INSTRUCTIONS
i
Danger - Warning
Authorised technical service personnel
must perform installation and assembly
operations.
Proceed as indicated.
1. Remove the screws that block the
machine to the wooden pallet.
2. Insert the fork lift's forks in the specially
designed spaces provided in the base.
3. Lift the machine from the pallet.
4. Insert supporting legs in the place of the
blocking screws.
i
Danger - Warning
To perform the operation in safety, insert
some wooden spacers below the forks of
the lift truck and position all to the floor.
5. Place the machine in the area assigned
for assembly.
|
Important
It must be placed on a smooth, level
surface for assembly.
6. Use the support feet to level the
machine.
7. The machine can be fastened to the
floor, if required, by drilling holes in the
walls prepared on the support feet.
