SPIROR HP - DR
4.5.3.ASSEMBLY OF THE PRODUCT
INFEED UNITS (L = 1500 /
2500)
1. With machine equipped with belt infeed
units, remove the safety protection panel
(A).
2. Assemble the vertical guide units, if
available (optional).
Operation to be carried out only with
roller infeed units.
3. Position the infeed and outfeed units and fix them to the machine body with proper screws.
4. Level the units by adjusting support legs
(B).
