Appendix B Module Tag Definitions
Output Tags
Tab le 62 describes the 5094-OB32 module output tags.
5094-OW4IS Module Tags
This section describes the tags that are associated with the 5094-OW4IS module.
Input Tags
Tab le 63 describes the 5094-OW4IS module input tags.
Table 62 - 5094-OB32 Module Output Tags
Name Data Type Definition Valid Values
Ptxx.Data BOOL Current digital input value. • 0 = Off
•1 = On
STATUS
POWER
SAFETY DIGITAL 16 INPUT 24 VDC
5094-IB16S
5
5
TB3I
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Table 63 - 5094-OW4IS Module Safety Input Tags
Name Data Type Definition Valid Values
RunMode BIT The point’s operating state • 0 = Idle
•1 = Run Mode
ConnectionFaulted BIT Indicates if a connection is running.
The module sets this tag to 0 when connected. If the module
is not connected, it changes the tag to 1.
• 0 = Connection running
• 1 = Connection not running
DiagnosticActive BIT Indicates if any diagnostics are active or if the prognostics
threshold is reached.
• 0 = No diagnostics active
• 1 = One or more diagnostics are active or the
prognostics threshold is reached
DiagnosticSequenceCount SINT Increments for each time a distinct diagnostic condition is
detected, and when a distinct diagnostic condition
transitions from detected to not detected.
Set to zero by product reset or power cycle. Wraps from 255
(-1) to 1, skipping zero.
-128…+127
The value of 0 is skipped except during module
powerup.
Ptxx.Readback BOOL Indicates the current digital output value. • 0 = Off
•1 = On
Ptxx.Fault BOOL • Indicates that point data is inaccurate and cannot be
trusted for use in the application.
For more information, see Module Data Quality
Reporting on page 47.
• The channel is set to Not Used.
• 0 = Good data
• 1 = Bad data (faulted) or set to Not Used
If the tag is set to 1, you must troubleshoot the
module to correct the cause of the inaccuracy.
IMPORTANT: Once the condition that causes the
tag to change to 1 is removed, you must complete
the steps described in Safety Relay Output Fault
Reset on page 85 to reset this tag to 0.
If the tag is 1 because the channel is set to Not
Used, no action is required.
