90 Rockwell Automation Publication 5094-UM001E-EN-P - April 2020
Chapter 6 Configure the Standard Module
To add additional I/O modules with this method, complete one of the following:
• If you cleared the Close on Create check box when you created the first
I/O module, repeat steps 3
…6.
• If you did not clear the Close on Create checkbox when you created the
first I/O module, repeat steps 2
…6.
New Module
To use the New Module method with FLEX 5000 I/O modules, complete these
steps.
1. Right-click the FLEX 5000 EtherNet/IP adapter and choose
New Module.
TIP This example shows how to add an I/O module when the Logix Designer
application project is offline.
You can add new modules when the project is online, if desired. In this case,
the steps are similar to the steps described in Discover Modules
on page 88.
One exception is that, in step 1, you choose New Module instead of Discover
Modules.
