Rockwell Automation Publication 5094-UM001E-EN-P - April 2020 145
Module Tag Definitions Appendix B
5094-IA16 Module Tags
This section describes the tags that are associated with the 5094-IA16 module.
Configuration Tags
Tab le 32 describes the 5094-IA16 module configuration tags.
Input Tags
Tab le 33 describes the 5094-IA16 module input tags.
STATUS
POWER
DIGITAL 16 INPUT 24 VDC
5094-IB16
1
1
TB3
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Table 32 - 5094-IA16 Module Configuration Tags
Name Data Type Definition Valid Values
Ptxx.InputOffOnFilter SINT The amount of time that a signal must be in the on state
before the input data indicates the on state.
The amount of time is indicated using an enumeration. Not
all products support all enumeration values.
Ptxx depends on the number of counters that have been
configured.
• 13 = 1 ms
Ptxx.InputOnOffFilter SINT The amount of time that a signal must be in the off state
before the input data indicates the off state.
The amount of time is indicated using an enumeration. Not
all products support all enumeration values.
Ptxx depends on the number of counters that have been
configured.
• 16 = 10 ms
• 17 = 20 ms
Pt0x.FieldPowerDiagEn BOOL Determines whether the point faults when no field power is
present.
• If the input is powered from the SA, select this checkbox
to monitor the status of the SA power.
• If the input is powered from another power supply, do
not select this checkbox, so that the input continues to
work even when there is no SA power
• 0 = Field Power/SA Power Diagnostics is not sent
to the controller.
• 1 = Field Power/SA Power Diagnostics is sent to
the controller. Use this if the sensor uses the SA
power in the terminal base.
Table 33 - 5094-IA16 Module Input Tags
Name Data Type Definition Valid Values
RunMode BOOL The point’s operating state • 0 = Idle
•1 = Run Mode
ConnectionFaulted BOOL Indicates if a connection is running.
The module sets this tag to 0 when connected. If the module
is not connected, it changes the tag to 1.
• 0 = Connection running
• 1 = Connection not running
DiagnosticActive BOOL Indicates if any diagnostics are active or if the prognostics
threshold is reached.
• 0 = No diagnostics active
• 1 = One or more diagnostics are active or the
prognostics threshold is reached
DiagnosticSequenceCount SINT Increments for each time a distinct diagnostic condition is
detected, and when a distinct diagnostic condition
transitions from detected to not detected.
Set to zero by product reset or power cycle. Wraps from 255
(-1) to 1, skipping zero.
-128…+127
The value of 0 is skipped except during module
powerup.
