56 Rockwell Automation Publication 5094-UM001E-EN-P - April 2020
Chapter 4 Output Module Features
•8-point standard relay output module, catalog number 5094-OW8I
•8-point standard relay output module for extreme environments,
catalog number 5094-OW8IXT
Features Specific to All
FLEX 5000 Output Modules
The following topics are specific to all FLEX 5000 output modules.
Output State Change Time
Tab le 11 lists the time that it takes for FLEX 5000 output module outputs to
change state after a command.
Configurable Point-level Output State in Program Mode or
Communications Fault Mode
You can configure individual output points to specific states when the module is
in Program mode or Communications Fault mode. The following output states
are available:
•Off
• On (This option is not available for Safety applications.)
• Hold last state
To see where to configure the output states in Program mode or
Communications Fault mode, see the following:
• 5094-OA16 and 5094-OA16XT modules - page 103
• 5094-OB8 and 5094-OB8XT modules - page 104
• 5094-OB16 and 5094-OB16XT modules - page 104
• 5094-OB16S and 5094-OB16SXT modules - page 117
• 5094-OB32 and 5094-OB32XT modules - page 104
STATUS
POWER
SAFETY DIGITAL 16 INPUT 24 VDC
5094-IB16S
5
5
TB3I
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
STATUS
POWER
DIGITAL 16 INPUT 24 VDC
5094-IB16
1
1
TB3
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Safety Modules
Standard Modules
Table 11 - Time for a Module Output to Change States
Module Time
(1)
(1) The times that are listed in Table 11 are from the time the module receives the message.
5094-OA16, 5094-OA16XT 1/2 AC cycle (Typical)
5094-OB8, 5094-OB8XT 100 μs
5094-OB16, 5094-OB16XT 100 μs
5094-OB16S, 5094-OB16SXT 4.5 ms
5094-OB32, 5094-OB32XT 100 μs
5094-OW8I, 5094-OW8IXT 10 ms
5094-OW4IS, 5094-OW4ISXT 20 ms (Off to On)
10 ms (On to Off)
(2)
(2) Under no fault condition.
