Rockwell Automation Publication 5094-UM001E-EN-P - April 2020 43
Digital I/O Module Operation in a Logix 5000 Control System Chapter 1
Different Configuration Owner
When a controller owns the I/O module configuration, other controllers can
listen to the input module. In this case, the module configuration signature in the
Logix Designer project for any listening controller must match the one in the
owner-controller project.
Reset FLEX 5000 I/O Safety Modules to Out-of-Box State
If a FLEX 5000 I/O safety module was used previously, you must clear the
configuration ownership before you can install it on a safety network. That is,
you must return the module configuration to its out-of-box state.
When a FLEX 5000 I/O safety module is in the out-of-box state, its
configuration is not owned by a controller.
The Safety category on the Module Properties dialog box displays the module
Configuration Ownership. The Logix Designer application project must be
online to check.
If the module configuration is owned, the Safety category displays whether the
controller for the opened project owns the module configuration or another
controller owns it.
For information on how to reset the module in the Logix Designer application,
see Reset to Out-of-Box Configuration
on page 120.
You cannot reset the module to its out-of-box configuration if either of the
following conditions is true:
• Pending edits to the module properties exist
• Safety signature exists in the controller project
TIP If the safety module is configured for inputs only, you can copy and paste
the configuration signature from one project to the other.
If the safety module has safety outputs, for example, the 5094-OB16S
module, the configuration signature parameter is disabled.
