Rockwell Automation Publication 5094-UM001E-EN-P - April 2020 105
Configure the Standard Module Chapter 6
Edit 5094-OW8I Module
Configuration Categories
In addition to the General, Connection, and Module Info categories, the Points
category is available when you configure a 5094-OW8I module.
Points Category
The Points category shows the configuration options available for each point.
You can configure the following parameters from the Points category:
• Output State During Program Mode
• Output State During Fault Mode
• Fault Mode Output State Duration
• Fault Mode Output State Final State
• Output State When Communications Fail in Program Mode
IMPORTANT If you use the Listen Only Data connection type, the Points Category does
not appear.
