Rockwell Automation 5094-IA16 User Manual

158 Rockwell Automation Publication 5094-UM001E-EN-P - April 2020
Appendix B Module Tag Definitions
5094-IB32 Module Tags
This section describes the tags that are associated with the 5094-IB32 module.
Configuration Tags
Tab le 44 describes the 5094-IB32 module configuration tags.
STATUS
POWER
DIGITAL 16 INPUT 24 VDC
5094-IB16
1
1
TB3
FLEX 5000
TM
I/O
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Standard Modules
Table 44 - 5094-IB32 Module Configuration Tags
Name Data Type Definition Valid Values
Counterxx.InputOffOnFilter SINT The amount of time that a signal must be in the on state
before the input data indicates the on state.
The amount of time is indicated using an enumeration. Not
all products support all enumeration values.
•9 = 0 μs
• 10 = 100 μs
• 11 = 200 μs
• 12 = 500 μs
• 13 = 1 ms
• 14 = 2 ms
• 15 = 5 ms
• 16 = 10 ms
• 17 = 20 ms
• 18 = 50 ms
Counterxx.InputOnOffFilter SINT The amount of time that a signal must be in the off state
before the input data indicates the off state.
The amount of time is indicated using an enumeration. Not
all products support all enumeration values.
•9 = 0 μs
• 10 = 100 μs
• 11 = 200 μs
• 12 = 500 μs
• 13 = 1 ms
• 14 = 2 ms
• 15 = 5 ms
• 16 = 10 ms
• 17 = 20 ms
• 18 = 50 ms
Counterxx.RolloverAtPreset BOOL Determines whether the simple counter will rollover to 0
when it reaches O:Preset (1) or at 2147483647 (0).
• 0 = Maximum value
•1 = Preset value
Ptxx.InputOffOnFilter SINT The amount of time that a signal must be in the on state
before the input data indicates the on state.
The amount of time is indicated using an enumeration. Not
all products support all enumeration values.
Ptxx depends on the number of counters that have been
configured.
•9 = 0 μs
• 10 = 100 μs
• 11 = 200 μs
• 12 = 500 μs
• 13 = 1 ms
• 14 = 2 ms
• 15 = 5 ms
• 16 = 10 ms
• 17 = 20 ms
• 18 = 50 ms
Ptxx.InputOnOffFilter SINT The amount of time that a signal must be in the off state
before the input data indicates the off state.
The amount of time is indicated using an enumeration. Not
all products support all enumeration values.
Ptxx depends on the number of counters that have been
configured.
•9 = 0 μs
• 10 = 100 μs
• 11 = 200 μs
• 12 = 500 μs
• 13 = 1 ms
• 14 = 2 ms
• 15 = 5 ms
• 16 = 10 ms
• 17 = 20 ms
• 18 = 50 ms
Ptxx.ChatterTime INT A value from 1…10000 ms in whole ms increments. 1…10000
Ptxx.ChatterCount SINT The number of input changes that are considered Chatter. • 0 = Disabled
• 2…127 = Enabled
