Chapter 7 Configure and Replace Safety Modules

Safety Category

The Safety category lets you set the RPI rate.

To change the Connection Reaction Time Limit configuration, click Advanced.

For more information on the RPI and the Connection Reaction Time Limit

parameters, see Requested Packet Interval

on page 26.

IMPORTANT Remember, the Safety Task period determines the 5094-OB16S module RPI.

Need to add artwork.
