Publication 2094-UM001A-EN-P — September 2006
154 Troubleshooting the Kinetix 6000 Drive System
Bus Status LED Indicator
Temperature Fault LED Indicator
Shunt Fault LED Indicator
All SM Status LED Indicators
Bus Status LED Status Potential Cause Possible Resolution
Flashing
Normal condition when control power is applied and bus voltage is less than
60V dc.
N/A
Steady Green
Normal condition when control power is applied and bus voltage is greater
than 60V dc.
N/A
Off Control power is not present Internal power supply failure Replace shunt module.
Temp Fault LED Status Potential Cause Possible Resolution
Off Normal condition N/A
Steady Red
SM internal temperature
exceeds operating
temperature specification
Shunt module fan failed Replace shunt module.
Shunt module temperature exceeds rating
• Allow shunt module to cool.
• Reset faults.
• Verify IAM bus regulator configuration.
External over temperature
condition
External temperature switch is open
• Allow shunt module to cool.
• Reset faults.
• Verify IAM bus regulator configuration.
TS jumper is not present Install jumper.
Shunt Fault LED Status Potential Cause Possible Resolution
Off Normal condition N/A
Steady Red
Shorted internal or external
shunt resistor
Mis-wired shunt jumper or other short on RC
connector
• Correct mis-wire (shorted) condition.
• If problem persists, replace shunt module.
Mis-wired (shorted) external shunt wiring
SM Status LED Status Potential Cause Possible Resolution
• Bus Status
• Temperature Fault
• Shunt Fault
All three SM status LED
indicators flash
simultaneously
Shunt module hardware failure
• Cycle power.
• If problem persists, replace shunt module.
