Publication 2094-UM001A-EN-P — September 2006
Specifications and Dimensions 171
IAM (460V) Power Specifications
Specification
Description
2094-BC01-MP5-S 2094-BC01-M01-S 2094-BC02-M02-S 2094-BC04-M03-S 2094-BC07-M05-S
AC input voltage 324...528V rms
three-phase (360...480V nom)
AC input frequency 47...63 Hz
Main ac input current
(1)
Nom (rms)
Max inrush (0-pk)
10 A
10 A
24 A
20 A
44 A
34 A
71 A
56 A
DC input voltage (common bus follower) 458...747V dc
DC input current (common bus follower) 10 A 24 A 43 A 71 A
Control power ac input voltage
95...264V rms
single-phase (230V nom)
Control power ac input current
Nom (@ 220/230V ac) rms
Nom (@ 110/115V ac) rms
Max inrush (0-pk)
3 A
6 A
25 A
Nominal bus output voltage 650V dc
Line loss ride through 20 ms
Continuous output current
to bus (A
dc
)
10 A 24 A 43 A 71 A
Intermittent output current
to bus (A
dc
)
(2)
20 A 48 A 86 A 142 A
Bus overvoltage 825V dc
Bus undervoltage 275V dc
Internal shunt
Continuous power
Peak power
50 W
5600 W
200 W
22,300 W
Internal shunt resistor 115 Ω 28.75 Ω
Shunt on 805V dc
Shunt off 755V dc
Continuous power output to bus 6 kW 15 kW 27.6 kW 45 kW
Peak power output 12 kW 30 kW 55.2 kW 90 kW
Efficiency 95%
Converter inductance 250 μH125 μH75 μH
Converter capacitance 110 μF 220 μF940 μF 1410 μF
(1)
All 2094-xCxx integrated axis modules are limited to 2 contactor cycles per minute (with up to 4 axis modules), or 1 contactor cycle per minute (with 5 to 8 axis modules).
(2)
Intermittent output current duration equals 250 ms.
