Publication 2094-UM001A-EN-P — September 2006
Interconnect Diagrams 211
Coil Currents Rated at < 1.0 A
Coil Currents Rated at >1.0 A and ≤
1.3 A
Coil Currents Rated at >1.3 A and ≤
3.0 A
IMPORTANT
For brake requirements outside of these limits, an external relay
must be used.
Compatible Brake Motors Coil Current Compatible Brake Motors Coil Current
MPL-x15xx
(1)
0.48 A 1326AB-B4xxx 0.88 A
MPL-x2xx
(1)
0.51 A F-4030, -4050, and -4075 0.69 A
MPL/MPF/MPS-x310, -x320, -x330
(1)
0.50 A Y-1002 and -1003 0.26 A
MPL-x420, -x430, -x4520, -x4530, -x4540
(1)
0.64 A
Y-2006 and -2012 0.31 A
MPF-x430, -x4530, -x4540
(1)
Y-3023 0.37 A
MPG-x004
(1)
0.33 A TL-A110P-H, -A120P-H, and -A130P-H 0.208 A
MPG-x010
(1)
0.45 A
TL-A220P-H and -A230P-H 0.375 A
MPG-x025
(1)
TL-A2530P-H and -A2540P-H 0.396 A
MPG-x050
(1)
0.50 A TL-A410P-H 0.746 A
MPG-x110
(1)
1.0 A
(1)
Applies to 230V and 460V motors.
Compatible Brake Motors Coil Current Compatible Brake Motors Coil Current
F-6100, -6200, and -6300 1.30 A MPL-x520, -x540, -x560, -x580
(1)
1.05...1.28 A
H-6100, -6200, and -6300 1.13 A
MPF-B540
1326AB-B5xxx, and -B7xxx 1.20 A
(1)
Applies to 230V and 460V motors.
Compatible Brake Motors Coil Current Compatible Brake Motors Coil Current
H-8350 and -8500 2.20 A
MPL-B640, -B660, -B680, -B860, -B880,
-B960, -B980
1.91...2.19 A
