50 Rockwell Automation Publication 20P-TG002B-EN-P - February 2018
Chapter 3 Part Replacement Procedures
6. Remove the three stand-offs from the resolver interface board.
S15
XR
XA
XP3
XRE
XFCD
S21
S4
P2 P3
S1
TB1 TB2
XRE
S2
6
Tightening torque for re-
assembly is
0.7 N•m (6.2 lb•in)
Resolver interface
board
