PowerMonitor 5000 Unit Data Tables Appendix A
LoggingResults.TriggerData_Log (M6 and M8 model) X X X F70 861 14 page 393
LoggingResults.Power_Quality_Log (M6 and M8
model)
X X X F73 864 32 page 394
LoggingResults.Snapshot_Log (M6 and M8 model) X X X F81 872 2 page 395
LoggingResults.WaveformFileName (M6 and M8
model)
XXXST788691page 396
LoggingResults.Waveform_Log (M6 and M8 model) X X X F80 871 43 page 396
LoggingResults.EN50160_Weekly_Log (M8 only) X X F83 874 13 page 398
LoggingResults.EN50160_Yearly_Log (M8 only) X X F84 875 37 page 399
PowerQuality.RealTime_PowerQuality X X X X F54 845 56 page 401
PowerQuality.EN61000_4_30_HSG (M8 only) X X F88 879 23 page 403
PowerQuality.EN61000_4_30_THD (M8 only) X X F90 881 46 page 404
PowerQuality.EN61000_4_30_Sequence (M8 only) X X F91 882 13 page 406
PowerQuality.EN61000_4_30_Aggregation (M8 only) X X F92 883 46 page 407
PowerQuality.EN50160_Compliance_Results (M8
only)
X X F93 884 40 page 409
PowerQuality.Harmonics_Results (M6 and M8 model) X X X F69 860 37 page 411
PowerQuality.IEEE1159_Results (M6 and M8 model) X X X F72 863 26 page 413
PowerQuality.Synchro_Phasor_Results X X X F103 894 26 page 415
PowerQuality.IEEE519_ Results (M6 and M8 model) XXXFn (varies)Varies44page 417
PowerQuality.Harmonics Results (M6 and M8 model) XXXFn (varies)Varies35page 422
PowerQuality.EN61000_4_30 Harmonic and
Interharmonic Group Results (M8 only)
XXFn (varies)Varies54page 428
Table 39 - Data Table Summary Index (continued)
Name of Data Table Read M5 M6 M8 Write PCCC File
Number
CIP Instance
Number
No. of Table
Parameters
See Page
