Bulletin 284G Programmable Parameters for Sensorless Vector Controllers 4-27
Stop Mode
Valid Stop Mode for the Bulletin 284G ArmorStart are the following:
0 = Ramp, CF Ramp to Stop. Stop command clears active fault.
1 = Coast, CF Coast to Stop. Stop command clears active fault.
2 = DC Brake,CF DC Injection Braking Stop. Stop command clears active fault.
3 = DCBrkAuto, CF DC injection Braking with Auto Shutoff.
Standard DC Injection Braking for value set in Parameter 180 (DC Brake Time) or
Drive shuts off if the drive detects that the motor is stopped. Stop command clears
active fault
4 = Ramp Ramp to Stop
5 = Coast Coast to Stop
6 = DC Brake DC Injection Braking Stop
7 = DC BrakeAuto DC Injection Stop with Auto Shutoff.
Standard DC Injection Braking for value set in Parameter 180 (DC Brake Time)
or
Drive shuts off if current limit is exceeded
8 = Ramp + EM B, CF Ramp to Stop with EM Brake Control. Stop command clears
active fault.
9 = Ramp + EM Brk Ramp to Stop with EM Brake Control.
Parameter Number 137
Related Parameters
136, 180, 181, 182, 205, 260,
261
Access Rule GET/SET
Data Type UINT
Group Basic Program
Units —
Minimum Value 0
Maximum Value 9
Default Value 9
Speed Reference
Valid Speed References for the Bulletin 284G ArmorStart are the following:
1 = Internal Freq
2 = 0…10V Input
4 = Preset Freq
5 = Comm port
6 = Stp Logic
9 = Jog Freq
Note: Option 2 must be selected when using 0…10V Analog Input.
Parameter Number 138
Related Parameters
101, 102, 112, 139, 140, 151,
152, 153, 154, 169,
170…173, 174…177, 210,
211, 213, 232, 240…247,
and 250…257
Access Rule GET/SET
Data Type UINT
Group Basic Program
Units —
Minimum Value 0
Maximum Value 7
Default Value 5
Accel Time 1
Sets the rate of acceleration for all speed increases.
Parameter Number 139
Related Parameters
138, 140, 151, 152, 153, 154,
167, 170…173, 174…177,
and 240…247
Access Rule GET/SET
Data Type UINT
Group Basic Program
Units 0.1 sec
Minimum Value 0.0 sec
Maximum Value 600.0 sec
Default Value 10.0 sec
Maximum Freq
Accel Time
-------------------------------------- A ccel Rate=
