Installation and Wiring 2-21
Figure 2.17 Bulletin 280G Safety ArmorStart
Motor
Connection
DeviceNet
Connection
(Mini/M18)
Local Disconnect
6 Inputs
(Micro/M12)
A1/A2
Control Brake
Control Power
Receptacle
3-Phase Power
Receptacle
LED Status
Indication
SM
