48
Chapter 3 Basic Operation
Chapter 3 Basic OperationChapter 3 Basic Operation
3-4 Moving the Tool
Manual Feed
Moving the tool manually is called "manual feed," and you can accomplish this using the feed buttons
in VPanel.
Note: Manual feed cannot be performed while a cutting operation is in progress.
Table Movement When a Y-axis Feed Button Is Clicked
Under the default setting, Y-axis movement assumes a direction of tool movement relative to the object
being cut. This means that clicking a Y-axis feed button makes the table move in a direction dierent
from what the arrow indicates.
Selecting one of these enables move-
ment by the specied number of steps
when a feed button is clicked.
1 step = 0.01 mm
Holding down a feed button performs
movement at the selected feed rate.
Feed buttons
Clicking these performs
manual feed for the tool
and the rotary axis.
P. 49, "About the Displayed
Tool Position"
To Next Page
