Chapter 5
Appendix
This section explains how to use the engraving cutter as well as the
maintenance method, countermeasures against the problems, and the
specications of the machine.
5-1 Using the Z0 Sensor ...................................................70
What’s a Z0 Sensor ....................................................... 70
Setting the Z Origin Using the Z0 Sensor ...................... 70
Setting the Thickness of the Z0 Sensor ......................... 72
5-2 Using the Engraving Cutter.........................................73
Installing the Engraving Cutter and Setting the Origin
Point .............................................................................. 73
5-3 Maintenance ...............................................................76
Cleaning ........................................................................ 76
Maintenance of the Spindle Unit.................................... 77
5-4 What to Do If... ............................................................78
5-5 Responding to an Error Message ...............................83
5-6 Power Rating and Serial Number Locations ...............86
5-7 NC Code Specications ..............................................87
Word List ....................................................................... 89
5-8 Specications ..............................................................91
Expansion Connector .................................................... 91
External View ................................................................. 92
Dimensional Drawings of the Table Area ....................... 93
Main Specications ........................................................ 94
System Requirements for USB Connection .................. 95
