5-8 Specications
94
Chapter 5 Appendix Chapter 5 Appendix
Chapter 5 Appendix Chapter 5 Appendix
Main Specications
MDX-40A
Cuttable material Resins such as chemical wood and modeling wax (metal not sup-
ported)
X, Y, and Z operation
strokes
X, Y, and Z: 305 x 305 x 105 mm (12 x 12 x 4.13 in.)
Distance from collet tip
to table
Maximum 123 mm ( 4.84 in.)
Workpiece table size Width x depth: 305 × 305 mm (12 x 12 in.)
Loadable workpiece
weight
4 kg (8.8 lb)
X-, Y-, and Z-axis drive
system
Stepping motor
Operating speed XY-axis : 7 to 3000 mm/min. (0.28 to 118 in./m)
Z-axis : 7 to 1800 mm/min. (0.28 to 70.8 in./m)
* 2 mm/min step for 7 to 60 mm/min(0.28 to 2.36 in./m)
* 60 mm/min step for 60 to 3000 mm/min(2.36 to 118 in./m).
Software resolution 0.01 mm/step (0.00039 in./step) (RML-1),
0.001 mm/step (0.000039 in./step) (NC code)
Mechanical resolution 0.002 mm/step (0.000078 in./step) (micro-step control)
Spindle motor Brushless DC motor, maximum 100W
Spindle rotation 4,500 to15,000 rpm
Tool chuck Collet method
Interface USB (compliant with Universal Serial Bus Specication Revision
1.1)
Control command sets RML-1, NC code
Power requirements Voltage and frequency: AC 100 to 240 V ±10%, 50/60 Hz (overvolt-
age category II, IEC 60664-1)
Required power capacity: 2.1 A
Power consumption Approx. 210 W
Operating noise During operation: 56 dB (A) or less (when not cutting), during
standby: 42 dB (A) or less
External dimensions Width x depth x height : 669 x 760 x 554 mm (26.4 x 30 x 21.9 in.)
Weight 65 kg
Installation Environment Operating environment: Temperature of 5 to 40°C (41 to 104 °F),
35 to 80% relative humidity (no condensation)
Ambient pollution degree: 2 (as specied by IEC 60664-1)
Included items Power cord, USB cable, collet , Z0 sensor, hexagonal screwdrivers,
hexagonal wrench, spanners, User’s Manual (this document), SRP
Player Installation and Setup Guide, SRP Player CD-ROM, Roland
Software Package CD-ROM
